SmallHD Ultra 7 RX 1500
The SmallHD Ultra 7 RX1500 is a professional 7-inch on-camera monitor with an integrated Teradek Bolt 6 RX 1500 wireless receiver for low-latency video transmission. The Full HD display delivers a brightness of 2300 nits and features a high-contrast 10-bit LCD touchscreen panel. The monitor supports 6G-SDI workflows up to DCI 4K and includes extensive camera control functionality via Ethernet and USB. Its durable housing is IP54-rated for protection against dust and water splashes and is designed for professional production environments.
#7"#Bolt6#Handheld#Monitoring#RX1500#SmallHD
Technical Facts
| Display Size | 7 Inch |
| Resolution | 1920 × 1200 Pixels |
| Display Type | LCD Touchscreen |
| Brightness | 2300 Nits |
| Contrast Ratio | 1000:1 |
| Color Depth | 10-Bit |
| Wireless System | Integrated Teradek Bolt 6 RX 1500 |
| Wireless Range | Up to 1500 ft / approx. 457 m |
| Video Inputs | 6G-SDI, HDMI |
| Supported Formats | Up to DCI 4K30 via SDI |
| Camera Control | Compatible with ARRI, Sony VENICE, RED |
| Protection Rating | IP54 |
| Power Supply | V-Mount Micro Battery Plate |
| Features | PageOS, Function Buttons, 4K Monitoring, Wireless Video Transmission |
